Battery voltage 18 V
Weight excl. battery 1.5 kg
No-load speed (1st gear / 2nd gear) 0 – 480 / 0 – 2,100 rpm
Chuck capacity, min./max. 1.5 / 13 mm
Torque settings 25+2
Torque (soft/hard/max.) 47/85/110 Nm
Battery type Lithium-ion
Max. impact rate 31,500 bpm
Drilling diameter
Max. drilling diameter in wood 82 mm
Max. drilling diameter in steel 13 mm
Max. drilling diameter in masonry 16 mm
Screw diameter
Max. screw diameter 12 mm
Total vibration values (Drilling in metal)
Vibration emission value ah 2.5 m/s²
Uncertainty K 1.5 m/s²
Total vibration values (Impact drilling in masonry)
Vibration emission value ah 15.5 m/s²
Uncertainty K 1.5 m/s²
